| 起源の場所: | 成都中国 |
|---|---|
| ブランド名: | HLLP |
| モデル番号: | DN1102 |
| 最小注文数量: | 100セット |
| 価格: | US$ 0.4-5 per set |
| パッケージの詳細: | カートンパレット、木製のケース、または必要に応じて |
| 受渡し時間: | 10〜20日 |
| 支払条件: | T/T |
| 供給の能力: | 1か月あたり100000セット |
| 製品タイプ: | 事前に形成されたデッドエンドキット | 長持ちするパフォーマンス: | 50年以上のサービスライフ |
|---|---|---|---|
| 適用する: | ACSR、AAC、AAAC、およびOPGW導体の場合 | インストール: | ツールフリー、ハンドインストール |
| 重要な利点: | 優れた振動減衰と疲労抵抗 | 品質が保証されました: | 100％RB（定格破壊強度）を達成する |
| 普遍的な適用: | ACSR、AAAC、ADSSに適合します | ||
| ハイライト: | preformed dead end cable termination,secure preformed dead end,reliable cable termination solution |
||
Key Features:
High Tensile Strength: Constructed from premium materials to withstand extreme mechanical loads.
Corrosion Resistance: Galvanized or aluminum alloy options offer long-lasting protection against harsh weather and corrosive environments.
Easy Installation: Preformed design allows for quick, tool-free installation, reducing labor time and costs.
Versatile Compatibility: Suitable for ACSR, AAC, AAAC, and other common cable types.
Enhanced Safety: Eliminates the need for splices or clamps, minimizing potential failure points.
| Parameter / Specification | Model PD-ACSR1 | Model PD-ACSR2 | Model PD-AAAC1 | Model PD-ADSS1 | Notes |
|---|---|---|---|---|---|
| Applicable Cable Type | ACSR | ACSR | AAC/AAAC | ADSS & OPGW | - |
| Cable Diameter Range (mm) | 10.0 - 14.0 | 14.1 - 18.0 | 8.0 - 12.0 | 10.0 - 16.0 | Custom sizes available |
| Ultimate Breaking Load (kN) | ≥ 30 | ≥ 50 | ≥ 20 | ≥ 25 | Meets IEC 61284 standards |
| Weight (kg per unit) | 0.45 | 0.75 | 0.35 | 0.50 | ± 0.05 kg |
| Material | Galvanized Steel Wire | Galvanized Steel Wire | Aluminum Alloy | Aluminum Alloy | Highly corrosion-resistant |
| Galvanization Type | Class A / Special | Class A / Special | - | - | Upon request |
| Operating Temperature | -40°C to +80°C | -40°C to +80°C | -40°C to +80°C | -40°C to +80°C | |
| Standard Compliance | IEC 61284, ASTM | IEC 61284, ASTM | IEC 61284, ASTM | IEC 61284, ASTM | Customizable to other standards |
Applications:
Overhead power transmission and distribution lines.
Telecommunication and fiber optic cable support.
Railway electrification systems.
Renewable energy projects (e.g., wind and solar farms).
Trust our Preformed Dead End for a maintenance-free, secure cable termination that meets international standards. Boost your project’s efficiency and safety with our proven solution!
Our customization options include:
Material Specification: Choose from various materials like galvanized steel, aluminum alloy, or special coatings for enhanced corrosion resistance.
Precise Sizing: Get exact sizes tailored to your cable's diameter and tensile strength needs.
Special Packaging: Request specific packaging (e.g., master cartons, palletization) for easier logistics and on-site handling.
Branding & Marking: Add your company logo, product IDs, or QR codes for traceability and brand consistency.
Tell us your needs, and we'll engineer the solution.
